Horúcovzdušná stanica YIHUA 853D+ 3A

 YH-853D 3A 4 LED with USB new type 3in1 soldering rework station with power supply

1.Based on the Company’s revolutionary, innovative design and meeting existing demands of the communication market, this

three-in-one machine uses the latest chip technology and integrates a DC power supply, hot air gun, and soldering station!

2.Temperature controls utilize core technology, adopting  microprocessor-PID programming for high-speed 100ms real-time tracking of air gun outlet temperatures and soldering iron tip temperatures, with real-time calibration! Outlet temperatures are extremely stable.

3. With PID high-speed 100ms rapid temperature calibration, conversions are energy-efficient, providing constant temperature power consumption at levels much lower than comparable machines, equating to greater energy savings!

4. The air gun handle wire employs a high-temperature silicone wire (undamaged when 300^osoldering tip contacts silicone wire for 30 seconds), stainless steel tubing, and a cutting-edge ceramic framed heating core for extremely stable and reliable performance!

5.soldering iron handle wire employs a high-temperature silicone wire (undamaged when 300^osoldering tip contacts silicone wire for 30 seconds); the heating element employs an imported high-power heating element for fast temperature compensation, particularly suitable for desoldering crude terminals, large joints, and difficult to reach spots, not to mention general solder joint desoldering.

6. The air gun features manual/automatic work mode conversion

7.The soldering iron features a sleep function that can be set 10 minutes.

8.This new type add to 5V output USB interface ,it more convenience repair mobile phone,also can use power supply for mobile.

9.All parts is LED digital display ,and the current is 4 digital precise display current value,the current value can precise display mA value.it is very directly perceived through the senses.

10.The soldering iron has an iron tip cleaner and internal rosin. The rosin aids in the soldering of circuit boards by removing oxide films on the iron tip, reproduces oxidation, reduces iron tip surface tension, and rapidly removes oxides.

11. Pioneering with handle safety protection, an industry-first, a docked handle in the handle holder is required each time prior to machine operation. If not (placed) in the handle holder, the operator will not be able to detect compliance with safety instructions and the machine will not work. The purpose of such a function is to prevent handle misplacement or accidental placement in unsafe or flammable (work) locations that could lead to undesirable consequences.

Parameters

 What's in the box :

* main unit + gun + power cord
* guide
* soldering iron
* soldering iron holder +gun frame+ cable
* 4nozzles

 Application Scope

      1.Electronic product assembly for industrial production

            2.Product development for scientific research departments

 3.Repair industry for electronic product inspection and maintenance

 4.Soldering operations for electricians in various enterprises and institutions

 5.Electronic assembly for electronic technology enthusiasts

 6.Student skills training  for a variety of electrical colleges

 7.Suitable for a variety of component desoldering and soldering, such as: SOIC, CHIP, QFP, PLCC,

  BGA, SMD, etc.

 8.Suitable for heat shrinking, drying, painting, adhesive removal, thawing, preheating, plastic

  welding, etc.

 9.DC power supply suitable for scientific research, product development, laboratories, laptop

    maintenance, etc.
